Features
- 1/4" CMOS Sensor
- 25/30fps@720P
- Resolution: 1 Megapixel
- High speed, long distance real-time transmission
- HD and standard definition switchable
- Low Illumination, Day/Night(ICR), AWB, AGC, BLC, 3D-DNR
- Lens: 3.6mm Board Lens
- Max. IR LEDs length 30m
- DC12V
Specifications
|
Model |
E-C03DA100 |
|
Camera |
|
|
Imaqe sensor |
1/4" CMOS |
|
Effective Picture Elements (HxV) |
PAL:1280(H)x720(V); NTSC:1280(H)x720(V) |
|
Minimum Illumination |
0.4Lux@( F1.2,AGC ON ) 0 LUX with IR |
|
Auto Electronic Shutter |
1/3s~1/100,000s |
|
Video Frame Rate |
30fps@720P; 30fps@960P |
|
Synchronous System |
Internal, Negative sync. |
|
Video Output |
1-channel BNC high definition video output |
|
Scanning System |
2:1 interface |
|
Camera Features |
|
|
IR Distance |
30 Meters (with 3PCS IR LED Arrays) |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
WDR |
N/A |
|
Noise Reduction |
2D/3D |
|
Picture Adjustment |
Yes |
|
Lens |
|
|
Focus Length |
3.6mm |
|
Focus Control |
Fixed |
|
Lens Type |
Fixed |
|
Pixels |
2 Megapixels |
|
General |
|
|
Power/Current |
DC12V(+/-10%)/350mA |
|
Anti-cut Bracket |
N/A |
|
Operation Temperature |
-10~+45°C RH95% MAX |
|
Storage Temperature |
-30~+60°C RH95% MAX |
|
Dimension |
£94 x 69(H) mm |
|
Weight |
0.3Kg |
|
Material |
Plastic |
